INSTALLATION / 5

Installation

PLACEMENT

Refer to Fig. 1.

• Set the media tank on a solid, level surface near water,

drain and electrical facilities. Place the outlet (black

coupling) of the tank on the left.

• Set the brine system on a flat, smooth, solid structure as

near the media tank as possible.

MOUNT THE CONTROL VALVE

See Fig. 2.

1. Remove the two plastic caps from the tank couplings and

lubricate the two O-rings with silicone lubricant. NOTICE:

Do not use a petroleum base lubricant, for this will cause

swelling of the rubber parts.

2. NOTICE: The black molded tank adapter is marked with

"IN" and "OUT", corresponding to the inlet and outlet of

the tank. Position the tank with the inlet coupling on the

right and the outlet coupling on the left.

3. The control valve is marked also with "IN" and "OUT"

(Fig. 2). Place the control onto the tank with the inlet and

outlet of the control corresponding with the inlet and

outlet of the tank. Press firmly onto the couplings.

4. Locate the two U-clamps and screws in the small parts

package. Install the clamps on both sides of the control as

indicated in Fig. 2 and secure them with the screws.

FIG. 1
